1230-205-51-3

2.00mm Simple Ejector Header 2x10POS SMT colloid height 5.8 contact plating Gold flash LCP Black UL94V-0 with Specification A 6.7/B 4.00/C 6.5 with positioning column Tape&Reel Packing

1230-XX1-DX-X

2.00mm Simple Ejector Header 2×04~2x10PIN,2x13,...,25POS SMT colloid height 6.4 contact plating Au 0.38μm Sn，Au 0.76μm Sn，Gold flash LCP Black UL94V-0 with Specification A 7.6/B 3.60/C 5.3 without or with positioning column Tape&Reel Packing

1230120X

1230 series Simple Ejector housing assembly 2.00mm Female 2×04~2x09POS PA66 Black UL94V-0 with drawstring structure

1236-105-J1-3

2.54mm Simple Ejector Header 2X05POS SMT contact plating Gold flash LCP Black UL94V-0 with Specification A 10.5/B 9.5 Tape&Reel Packing

12361106

1236 series Female Housing Pitch 2.54mm 2X3POS PA66 Black UL94V-0 fan connector with High 11.89 Width 10.0

12363022

1236 series Female Terminal phosphor bronze 1.27umNi+3~5um tinned under plated fan connector

1262-141-41-1

2.54mm Receptacle 2X07POS Double Row Straight Solder colloid height 8.5 contact plating Gold flash PBT Black UL94V-0 with Harpoon lower plate size 3.00

1262-261-41-1

2.54mm Receptacle 2X13POS Double Row Straight Solder colloid height 8.5 contact plating Gold flash PBT Black UL94V-0 with Harpoon lower plate size 3.0

1292-401-41-3

CONN Receptacle 2x20POS 2.00mm Straight Solder double row colloid height 6.4 contact plating Gold flash LCP Black UL94V-0 with Lower plate size 3.0 harpoon

1292-XXX-0X-3

CONN Receptacle 2x10POS 2.00mm Straight Solder double row colloid height 6.4 contact plating Gold flash LCP Black UL94V-0 with Lower plate size 2.3 harpoon

1296-122-41-C

CONN Receptacle 2x12POS 2.00mm SMT Shrapnel double row colloid height 4.30 contact plating Gold flash LCP Black UL94V-0 without 1、2、23、24POS

1296-XX2-4X-3

CONN Receptacle 2x05,2x25POS 2.00mm SMT shrapnel double row colloid height 4.30 contact plating Au 0.38μm Sn LCP Black UL94V-0 with Specification A 6.00/B 4.60

1296-XX2-XX-3

CONN Receptacle 04,06,14,25,48+5POS 2.00mm SMT shrapnel double row colloid height 4.30 contact plating Gold flash,Au 0.25μm ，Au 0.38μm, Au 0.76μm LCP Black UL94V-0 with Specification A 6.00/B 4.60

1341-XX7-17-3

1.25mm Wafer Connector 2X10,2×15,2X20P Type 7 (without horn) Straight SMT contact platingAu 0.38μm Sn LCP Black UL94V-0

1343-062-1B-D

2.50mm Wafer Connector 06P Right Angle male Solder Contact plating Sn PA66 Natural UL94V-0 with Angle lower plate size 3.30

1343-XX1-XB-N

2.50mm Wafer Connector 02~15PINP Straight male Solder Contact plating Sn LCP Natural UL94V-0 with lower plate size 3.3, 4.3

1343-XX5-XX-X

2.50mm Wafer Connector 04P Straight male Press-Fit Contact plating Sn LCP ,PA66 Natural UL94V-0 with lower plate size 3.3

13431125

2.5mm Housing 1343 Fan connector 09P Straight female PA66 Black UL94V-0

13431126

2.5mm Housing 1343 Fan connector 09P Straight male PA66 Black UL94V-0

13432116

1343 series Housing female Wafer Connector 16P Type 1( middle latch) PA66 Black UL94V-0

13433034

1343 series Male Terminal Fan connector 09P upgraded version contact plating Sn 3~5μm

13433035

1343 series Male Terminal Fan connector 09P upgraded version contact plating Sn 3~5μm

1344-041-2B-D

3.96mm Wafer Connector 04P Straight male Solder Contact plating Sn PA66 Natural UL94V-0 Specification A 3.7/B 14.6

1344-XX3-XX-X

3.96mm Wafer Connector 02,03,06P Straight male Solder Through hole Contact plating Au0.076μm, Sn LCP Natural UL94V-0 with lower plate size 3.3

1408-091-11-1

CONN D-SUB Standard PCB Plug 09POS Right Angle Solder Contact plating Gold flash PBT Black UL94V-0 Front shell salt spray 24H with Front screw 90120018/rear gasket 14085003+ harpoon 14085002

1408-092-11-1

CONN D-SUB Standard PCB Receptacle 09POS Right Angle Solder Contact plating Gold flash PBT Black UL94V-0 Front shell salt spray 24H with Front nut 90120018/rear gasket 14085003+ harpoon 14065003

1408-XX7-XX-3

CONN D-SUB standard PCB plug Right Angle 09POS Solder contact plating Au0.38μm Sn ,Gold flash Sn LCP black UL94V-0 front shell salt spray 24H with Ultrashort type front screw /Rear gasket + harpoon ,front nut 14075003/ Rear gasket 14085014+ harpoon 14083087

1441-090-00-3

CONN D-SUB BACKSHELL 09POS ABS Black UL94V-0

1632-061-09-Y

CONN Ф3.50mm stereo Audio Socket 06POS Right Angle Solder contact plating Au 0.076μm PA46 Black UL94V-0 with Standard Straigh structure

1822-323-XX-A

DIN41612 Connector 2.54mm Type C Right Angle male 3×32POS Solder contact plating PdNi 0.38μm + Au 2μ""Min， Gold flash Sn PBT Gray UL94V-0 with lower plate size 2.75 Riveted hole 2.5

1822-332-37-A

DIN41612 Connector 2.54mm Type R Straight male 3×32POS Solder contact plating Au 0.38μm Sn PBT Gray UL94V-0 with lower plate size 5.00

1865-261-08-1

CONN MDR 1.27mm plug vertical 26POS Solder contact plating Au 0.76μm Sn PBT black UL94V-0
